FBD-III ICU Hospital Bed

Short Description:

Product Detail

Product Tags

FBD-III ICU Hospital Bed prevue:

ICU nursing bed, or Intensive Care Unit, is a nursing bed used in Intensive Care units. Intensive medical care is along with the development of the health care professional, the birth of the new type of medical equipment and hospital by the improvement of the management system, a set of modern medical care technologies for the integration of medical organization management form. ICU beds are an essential medical device in the ICU ward.

FBD-III ICU Hospital Bed Technical parameters:

Full length 223cm
Including the side rails 105cm
Withink the side rails 99cm
Bed base height range(minimum-maximum height) 45-70cm
Patient touching surface 90*196cm
Back section panel 0-75
Leg section panel 0-45
Trendelenburg 0-15
Anti-Trendelenburg 0-15
Maximum safe load 250kg
Diameter of centrally control silent castor 12.5cm
Nurse controlled
Patient controller
4 linak electrical motor
Optional I.V.Pole
Drainage Hook
angle scale
Optional matterss
Bed bas:clod-rolled steel sheet

FBD-III ICU Hospital Bed advantage:

One, position adjusting medical mute motor USES the safe and reliable, stable performance, full electric control the whole of the bed body lift, back and thigh lift adjustment; Adjustable to cardiopulmonary resuscitation (CPR), heart, chair, “FOWLER position, MAX check bit, bit/anti’s position, at the same time, the central control system can display the back, legs plate, trevor’s/reverse’s Angle, side turn, meet clinical needs.

Second, turn aided by ICU center consciousness of patients, there are a lot of depth can’t roll over, need nurses often turn, scrub, prevent bedsore; Without turn assisted to complete a patient’s turn to swab usually need two or three staff to assist to complete, and nursing staff is very easy to hurt the waist, the clinical nursing staff to work a lot of trouble and inconvenience, modern standard in the sense of ICU beds can be very convenient to turn over to the side, by foot or hand control, easy to help the patient to realize turn over.

Three, convenient operating ICU beds can be multiple control the movement of the bed body, the bed on both sides of the fence, the end of the bed plate, a handheld controller, on either side of the foot control and so on have control function, so that nursing staff can according to the nursing rescue the most convenience to simple operation and control of hospital bed, there is also a key reset, and a key position, alarm from the bed, and other functions, is used to monitor transition convalescence patients walk, etc.

Four, accurate weighing function center of ICU critical patients need a lot of fluid exchange, every day is very important to intake and excretion, the traditional operation is manual record fluid intake, but it is easy to overlook the secretion of sweat or the body’s internal fat burning consumption quickly, when there is a precise weighing function, for the weight of the continuous monitoring of patients, doctors can compare the difference of the two data convenient to adjust treatment, treatment can improve the patients quality of the data management of change, the current mainstream of ICU beds weighing accuracy has reached 10-20 g.

Five, back X-ray films for critically ill patients with shooting can be done in the ICU ward, back configuration X-ray box of slide rail, don’t move the patient and the X-ray machine can be used for almost the whole body.

Six, flexible mobile and brake ICU ward center for nursing bed can be mobile and flexible, solid brake fixed for convenient nosocomial transshipment and rescue, etc., use more central control brake, medical universal wheel.

FBD-III ICU Hospital Bed logistics:
