FL720 LED Shadowless operating light

Short Description:


  • power: Low power consumption
  • heat dissipation: Small heat dissipation
  • Color temperature: Close to natural light
  • Radiation: Low radiation
  • Healthy: No damage to the patient
  • Life: 60000h
  • Product Detail

    Product Tags

    FL720LED Shadowless operating light:

    operating light Used for lighting surgical, use to observe small, low-contrast objects at different depths in the incision and body control. Since the surgeon’s head, hand and instrument may interfere with the shadow of the operation, the surgery should be to eliminate the shadow and Minimize color distortion. In  the surgical lamp also need to continue to work over a long period of time, but not too much heat, because the overheating that discomfort, the surgery would also can make the organization in surgical area dry. because overheating will make people ill operation, also can make the organization in surgical area dry.Shadowless operating lamp is Shared by a set of lights illuminate produced an effect, it is can increase the brightness, it is not at work to produce a shadow. The function used in the process of the doctor surgery can make doctors can more clearly see all kinds of organizations, to avoid operation error.

    FL720 LED Shadowless operating light technique Data:

    Model FL720 LED
    Diameter of dome 700mm
    Illumination 160,000lux
    Color temperature adjusment 3500-5000K
    Color indication index ≧95Ra
    Spot diameter 180~300mm
    L1+L2 Illumination depth 140/120cm
    Illumination-adjusting 10-100%
    Ultraviolet light irradicance within 40mm wave legth 0.002w/m2
    Focus mode Manual
    Power supply 220V/110V
    Frequency 50/60Hz
    Input power 100VA
    Light source LED
    Temperature rise at surgical ´s head ≦1℃
    Installed range(stand arm) 2800-3200mm
    Average service life ≧50,000hrs
    Optional Emergency battery,camera system

    FL720 LED Shadowless operating light use method:See our video instructions

    FL720 LED Shadowless operating light method:

    1,Check the fasteners of LED lights regularly to prevent accidents.

    2,If the LED lamp is found to be broken, the above method will be replaced. If the manufacturer is not allowed to change, notify the manufacturer for replacement.

    3,Always use wet soft cloth or sponge to touch a small amount of alcohol, scrub the surface of LED lamp and the Y tube, strictly prohibit water or other liquid to wash.

    4,To clean and disinfect the lamp’s handle regularly, which can be disinfected with 75% alcohol, formalin, new jal, or soas or fumigation; Not more than three days or surgery or 5 times every time before the operation, the lamp body handle coat for 138 ℃ high temperature cooking disinfection.

    5,there is any other malfunction, unable to deal with, please contact the company after-sales service department, have not been evaluated by the company personnel or full-time shadowless lamp repair personnel recognition, please do not remove the leds and control circuit at will.

    FL720 LED Shadowless operating light Product packaging:
