FDY-2C Electric hydraulic operating table

Short Description:

Product Detail

Product Tags

FDY-2C Electric hydraulic operating table instructions:

The electric operating table adopts microcomputer, dual controller control, multi-azimuth control and has the lock switch that prevents the wrong operation. All hydraulic control system adopts imported hydraulic component, which makes the whole machine have low noise and high safety reliability. This operating table is specially designed for ophthalmology and brain surgery, which can be performed by the doctor during operation. The whole table can be moved before and after the whole table, and the entire bit of the c-arm photo or perspective is achieved. Increase the width of the mesa to suit the current clinical needs. The mesa is divided into five movable segments: headboard, shoulder board, backboard, butt plate and leg plate. All the parts of the section are made of X-ray materials, and have a hidden guideway under each board, which can be carried out in a dark box

FDY-2C Electric hydraulic operating table technical parameters:

Model FDY-2C
Length 2170mm
Width 500mm
Adjuestable range of height 690~1100mm
Reversed Trendelenburg/Trendelenburg +30°/-30°
Later Tilt(left/right) +25°/-25°
Head rest(up/down) +45°/-90°
Foot Plate(up/down&horizontal positioning) +20°/-90°
Back Plate(up/down) +90°/-40°
Longitudinal Sliding 350mm
Wrist Plate up 120mm
Power 220V,50Hz/110v,60H
Double control system Hand remote controller,control panel at side of column
Build-in battery Standard configuration
One key rester Optional

FDY-2C Electric hydraulic operating table components:

Headboard: the pneumatic auxiliary device is easy to operate with the head plate.

Bed board: special compound material bed board, the x-line through rate is high, evenness is good, satisfy the film requirement of the film.

Mattess: once formed mattress, adopt international popular material, streamline appearance.

Line control manipulator: the shape design is fluent, accord with human body engineering, hold comfortable, integrate all control function. Logical self-locking function, prevent the operation of wrong operation.

Bed: special waterproof seal structure design, high quality stainless steel material, anti-fouling and rust prevention, guarantee the best sterilization requirement and anti-collision requirement.

Electric brake: can adjust according to the ground condition, lock, the bed stage does not appear the change of position, ensure the bed platform is firm and safe in the operation.

Standard size stainless steel side rail: can be fitted with various accessories.

Split-type foot plate: removable and disassembled, suitable for obstetrics and urology.

Base: thin base design, the hidden casters, not only ensure enough contact with the ground, to ensure that the operating table, but also can maximize the C – arm filming in surgery.

The bed side shifts: the package moves the translation function, let the perspective film in the operation have no dead Angle.

FDY-2C Electric hydraulic operating table logistics:
