PF-60-E Electric ceiling cranes pendant with single arms

Short Description:

  • power: Low power consumption
  • heat dissipation: Small heat dissipation
  • Color temperature: Close to natural light
  • Radiation: Low radiation
  • Healthy: No damage to the patient
  • Life: 60000h
  • Product Detail

    Product Tags

    PF-60-E Electric ceiling cranes pendant with single arms the safety instuructions:

    The medical electric elevator tower protects the ground impedance

    The protective grounding terminals of the equipment and all touching metal parts that have been protected to earth shall not exceed 0.1 ohms.

    2, the medical bridge type electric elevator tower equipment has the leakage current

    The normal state is not greater than 5mA, and the single failure state is not greater than 10mA

    3, medical bridge electric elevator electrical dielectric strength

    The power source portion of the network can be subjected to the normal wave ac voltage of 1500v. 50HZ for 1 minute dielectric strength test, no puncture or flashover phenomenon.

    Part 4, network power supply and medical bridge type electric cranes is greater than 1 m Ω insulation between metal parts.

    5, tailored to meet your personalized needs, to provide system solution for the hospital, according to the different needs of each customer and the actual situation, to design standardization in the operating room equipment configuration, the ICU work environment to carry on the design, the maximum to meet customer demand.

    The tower size, gas box, equipment tray, drawer, and fluid connection can be combined flexibly. Product standardization production, equipment and accessories are universality.

    Own installation, maintenance team, can meet the customer’s period limit in time. The product line is perfect, and our product line can produce hundreds of products from ordinary to high-end products that meet the needs of different levels of hospitals. Product line: hanging pillar, crane tower, suspension bridge three


    The company has the professional design production team, the professional customer service team. Set up a one-on-one project team for customers to enjoy the pre-sale, pre-sale, and after-sales service.

    Import quality, domestic price; Spend a light lift tower’s money to buy a heavy lift tower.

    PF-60-E Electric ceiling cranes pendant with single arms technical parameters:

    Model PF-60-E
    Mechanical brake
    Funcctional column(L=700mm)
    2#Tray(490*400mm) Customized
    stainless steel basket
    Gas outlet-German Standard Customized
    Narcotic AGSS outlet emission(jet/symphonic)
    Universal socket Customized
    Network communication interface socket RJ45
    Cable tracheal folder
    Cas plug
    Apply to:Surgery,Anesthesia,Endoscopy
    Can be customized

    PF-60-E Electric ceiling cranes pendant with single arms the reliabliity and stability:

    From German classic design, high strength aluminum alloy, modular combination. Whole sealing, streamline, surface oxidation spray treatment, never rust

    All air source terminals and tower hosts are both purveaux and German

    The gas outlet can be used by German famous brand, MEDICOP, which is reliable for 10 years.

    Electric socket can be used in France famous brand — -roger long, the quality is reliable, the assurance USES 10 years.

    Each rotating joint of the tower device is equipped with double brake: mechanical brake + pneumatic brake device to ensure that the tower equipment is accurate and safe and reliable.

    Each rotating joint is made of German famous brand, SKF, which is reliable for five years.

    Electric elevating motor USES the German famous brand

    Equipment pallet: high strength aluminum alloy whole drawing, with standard stainless steel rails

    The tray is optional 450mmx400mmmx30mm. Adopt 10mm by 25mm international standard edge rail. The rounded corners are designed with a drawer and the tray can move up and down.

    PF-60-E Electric ceiling cranes pendant with single arms logistics:
